Chipset

AMD® B850

Chip

AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors

Podrzana memorija

4x DIMM, Dual Channel DDR5, maximalno 256GB (4x 64GB), do 8000 MHz(OC)

PCI-E slotovi za nadogradnju

1x PCIe 5.0 x16, 1x PCIe 4.0 x4 in 16x slot

Video izlazi

DisplayPort x1, HDMI x1

Audio

Realtek® ALC897 HD Audio, 5.1 Channel

Mreža

Realtek® RTL8125BG 2.5 Gigabit Ethernet
M.2 WiFi 6 Module, Support 802.11 a/b/g/n/ac/ax, 2.4 GHz/ 5 GHz band, Bluetooth 5.3 Support

Priključci za USB

1x USB 3.2 Gen1 (1 x Type-C), 1x USB 3.2 Gen1 (2 x Type-A), 1x USB 2.0 (2 x Type-A)

Priključci nazad

1× DisplayPort, 1× HDMI™, 1× RJ45 LAN, 2× Wi-Fi Antenna
One-click Flash BIOS Button, 4× USB 2.0, 3× USB 3.2 Gen2 Type-A
1× USB 3.2 Gen2 Type-C, 3× Audio Jacks

M.2 slotovi

1x PCIe 5.0 M.2, 1x PCIe 4.0 M.2, 4x SATA

Dimenzije

Micro-ATX, 244x244mm

Debug LED

DRAM: Yellow, CPU: Red, GPU: White, Boot: Green

link ka stranici

https://www.sapphiretech.com/en/consumer/mb_pure_b850m-wifi#Specification
